Product Summary

? Electronic welders at fsw up to 20 kHz
? DC/DC – converter
? Brake chopper
? Switched reluctance motor

Parametrics

? Case temperature limited
to Tc = 125°C max.
? Recommended Top = -40 ... +150°C
? Product reliability results valid
for Tj = 150°C

Features

? IGBT4 = 4. generation fast trench IGBT
(Infineon)
? CAL4 = Soft switching 4. generation
CAL-diode
? Isolated copper baseplate using DBC
technology (Direct Bonded Copper)
? Increased power cycling capability
? With integrated gate resistor
? For higher switching frequenzies up to
20kHz
? UL recognized, file no. E63532
