Product Summary
A program operation can be performed in typical 200μs on the 528-bytes and an erase operation can be performed in typical 2ms on a 16K-bytes block. Data in the page can be read out at 42ns cycle time per byte. The I/O pins serve as the ports for address and data input/output as well as command input.
The on-chip write control automates all program and erase functions including pulse repetition, where required, and internal verification and margining of data. Even the write-intensive systems can take advantage of the K9F1208X0C′s extended reliability of 100K program/erase cycles by providing ECC(Error Correcting Code) with real time mapping-out algorithm.
Parametrics
Voltage on any pin relative to VSS: -0.6 to + 4.6V
VIN: -0.6 to + 4.6V
Temperature Under Bias: -10 to +125°C
Storage Temperature: -65 to +150°C
Features
? Voltage Supply
- 1.8V Device(K9F1208R0C) : 1.65V ~ 1.95V
- 2.7V Device(K9F1208B0C) : 2.5V ~ 2.9V
- 3.3V Device(K9F1208U0C) : 2.7V ~ 3.6V
? Organization
- Memory Cell Array : (64M + 2M) x 8bits
- Data Register : (512 + 16) x 8bits
? Automatic Program and Erase
- Page Program : (512 + 16) x 8bits
- Block Erase : (16K + 512)Bytes
? Page Read Operation
- Page Size : (512 + 16)Bytes
- Random Access : 15μs(Max.)
- Serial Page Access : 42ns(Min.)
? Fast Write Cycle Time
- Program time : 200μs(Typ.)
- Block Erase Time : 2ms(Typ.)
? Command/Address/Data Multiplexed I/O Port
? Hardware Data Protection
- Program/Erase Lockout During Power Transitions
? Reliable CMOS Floating-Gate Technology
- Endurance : 100K Program/Erase Cycles
with 1bit/512Byte ECC)
- Data Retention : 10 Years
? Command Register Operation
? Unique ID for Copyright Protection
? Package
- K9F1208U0C-PCB0/PIB0 : Pb-Free Package
48 - Pin TSOP I (12 x 20 / 0.5 mm pitch)
- K9F1208X0C-JCB0/JIB0: Pb-Free Package
63-Ball FBGA(8.5 x 13 x 1.2mmt)
- K9F1208B0C-PCB0/PIB0 : Pb-Free Package
48 - Pin TSOP I (12 x 20 / 0.5 mm pitch)
Diagrams
