Product Summary

? Case temperature limited to
Tc = 125°C max, recomm.
Top = -40 ... +150°C, product
rel. results valid for Tj = 150°

Features

? IGBT4 = 4. Generation (Trench)IGBT
? VCEsat with positive temperature
coefficient
? High short circuit capability, self
limiting to 6 x ICNOM
? Soft switching 4. Generation CAL
diode (CAL4)

Diagrams

? Case temperature limited to
Tc = 125°C max, recomm.
Top = -40 ... +150°C, product
rel. results valid for Tj = 150°
